Waste Plastic Baler Boosts Waste Acquisition Industry Development

 It is understood that with the progress of society and the development of science and technology, nowadays everything pays attention to mechanized operation. Even the scrap purchase industry is no exception, keeping up with the times. It is understood that in the waste acquisition industry, hydraulic balers have become a necessity in work and a good helper for compression packaging.

The reason why the hydraulic packer is loved by the waste acquisition industry is because of the following characteristics:

1. It has the characteristics of small size, light weight, small motion inertia, low noise, stable movement and flexible operation.

2. It adopts integrated hydraulic and electric control, which is simple and convenient to use. It can be stopped and operated at any working position, and it is easy to realize overload protection.

3. It has a wide range of applications. It can be used as a processing device for packaging waste plastic films, as well as a processing device for packaging and compacting similar products.

However, due to wear and tear of the parts during use, poor lubrication can cause damage to the parts, which may increase the occurrence of faults and accidents. Therefore, it is important to quickly find faults and eliminate them. Waste recycling equipment manufacturers remind you that you must identify the machinery and equipment produced by regular manufacturers when purchasing waste plastic balers. In addition, the waste sorting system manufacturer lists common faults and maintenance methods of balers:

Malfunction: Cut the steel strip continuously Cause:

1) The cutter is worn or faulty

Maintenance method: check whether the cutter or cutter holder is worn or faulty, if it is severely worn, it should be replaced

2) Air pressure decreases

Maintenance method: check whether the working pressure is normal;

The force of cutting the steel strip comes from the blocked cylinder. See fault phenomenon;

Check blocking operation

Malfunction: Not enough tension on the buckle jaws

Reason: Wear of clamping block coupling hole or coupling pin

Maintenance method: check these parts when groove depth is shallow, replace if necessary

According to market research, due to the increasing market demand for hydraulic plastic balers for waste plastic balers, choosing well-known brands can get good after-sales service and worry-free full-range technical support.

In addition, the waste plastic baler hydraulic baler is a new and advanced pneumatic packaging machine for balers. It is mainly used for iron and steel enterprises and non-ferrous metal enterprises to bundle various small specifications of pipes, plates, profiles and other products. Packaging of various products.

Hydraulic Baler Machine

Precautions for Installing Industrial Waste Baler

 1. The quality of the oil pump device has a very important impact on the smooth operation and service life of the pump, so the device proofreading operation must be carried out carefully and must not be rash. The support or base of the hydraulic pump of the industrial waste baler must be strong and strong, and the pump shaft of the hydraulic pump must be aligned with the motor.

2. The position, length and pipe diameter of the suction pipe of the oil pump should reach the accounting value, and strive to be simple; and let the pump not be larger than the cavitation margin during operation. The inner diameter of the suction pipe must not be less than the requirements of the rule. The suction pipe should not be too long. The bend at 90 degrees should not be more than two. It should be connected to the oil pump with a soft short connection.

3. The suction and discharge lines of the oil pump should have brackets.

4. The address of the installation oil pump should be spacious to facilitate maintenance work.

Hydraulic Cardboard Baling Machine China

Check the temperature and vibration of the bearings during the test run after the hydraulic oil pump device of the hydraulic cardboard baling machine china. After loosening the coupling, use a spirit level to place it on the pump shaft and base of the electric oil pump. Adjust the wedge pads, check the level of the unit, and tighten the anchor bolts appropriately to avoid loosening. In order to prevent impurities in the pipeline from entering the pump, a filter should be installed in the pump glue for the pipeline of the new device, and its useful section should be 2 to 3 times the section of the suction pipe.

There are many types of packing belts on the market, and the quality is also uneven. So what are the characteristics of industrial waste packing machines and what occasions can they be used for? It may be difficult for users who have never used packing belts. Relevant characteristics of the strap material of the auto tie baler machine.

1. Small elongation: The elongation is one-sixth that of polypropylene (PP) tape, which can maintain the tension for a long time.

2, beautiful and not rusty: no steel belt rust pollution pollution objects, the color is bright.

3, strong temperature resistance: melting point is 260 degrees, no deformation below 120 degrees.

4, strong tensile strength: not only the tensile strength of steel belt, but also the resistance to impact ductility, can ensure the safety of your product transportation.

5. Good economic benefits: The length of 1 ton plastic steel belt is equivalent to 6 ton steel belt. The unit price per meter is lower than steel belt, which can save you costs.

6, good flexibility: sharp edges without steel belt, safe operation, neither hurt your hands nor damage the bundled objects.

Baler Troubleshooting

 Because the packing machine is simple and convenient to operate, easy to use and highly effective, it is the reason why most companies choose the packing machine. There are many problems with the packing machine. When there is another failure, how should we solve it? Today, I will briefly introduce the problems and solutions of the baler today:

How to solve the problem of the poor bonding effect of the packing belt:

1. The temperature adjustment knob is not adjusted properly.

In the electrical appliance control box of the baler, above the circuit board, open the control box cover, you can clearly see an adjustment knob, turn it clockwise to increase the temperature, and vice versa. If the temperature is too high or too low, the bonding effect is not good, so do not adjust it too much at one time, generally it can be adjusted between 4-5.

2. The power supply voltage is abnormal.

This machine should use 220V voltage. In many factories, the voltage is often insufficient. If long cables are used again, the voltage will drop, the soup temperature will be lowered, and the motor will even be burned when it is tightly tied.

3. The pull spring of the electric heating monster fails.

The long tension spring on the electric monster is tired. In this way, the inability to send the hot head between the two upper and lower straps results in half or even less adhesion.

4. Improper adjustment of the position of the ironing head of the baler.

The hot head is too high or too low, or left or right, it can't heat the upper and lower two layers of packing belt when it collides with the packing belt or the cutter. It should be adjusted according to circumstances.

5. The middle knife bearing is broken.

The middle knife bearing is broken, so it cannot be pushed up, and the packing strap is pressed to make it stick.

6. The temperature inside the machine is too high.

Failure of the exhaust micro fan caused the temperature inside the packer to be too high.

7. The heat-resistant wire of the iron is faulty.

Check whether the heat-resistant wire is broken or burnt. If the nut is loose, tighten it.

8. The tightening force of the baler is adjusted too much. Properly adjust the tightening force.

Aging problems of automatic balers:

The maintenance condition of the horizontal baler machine often determines the service life of the machine itself and the operating efficiency of the machine. The automatic baler itself is actually classified as a high-precision machine. The high-precision machine's process requirements are: Very high, its structural parts must be strictly inspected before they can be mass-produced. The internal irregularity will cause problems and defects in the automatic baler often. Secondly, it is a matter of moderation of its own use. Everything has a freight cost. The high intensity and overload of the operation make the service life of the automatic baler shorten. Moderate attention should be given.

The daily maintenance of the automatic baler is the basic work of equipment maintenance, and it must be institutionalized and standardized. Regarding the regular maintenance work of the fully automatic baler, work quota and material consumption quota shall be formulated and evaluated according to the quota. The regular maintenance work of the fully automatic baler shall be included in the assessment content of the worker contract responsibility system.

Horizontal Baler Machine

The regular inspection of the fully automatic baler is a planned preventive inspection. In addition to the human senses, the inspection method is also performed according to the regular inspection card. Regular inspection is also called regular inspection. Fully automatic baler equipment should also be thoroughly inspected and responded: inspection of oil cylinders, oil pumps, electrical appliances, and various sliding parts. The maintenance of the fully automatic baler should be carried out according to the maintenance procedures. Fully automatic packing machine maintenance regulations are requirements and regulations for the daily maintenance of equipment. Adherence to the implementation of full automatic packing machine maintenance regulations can extend the service life of the equipment and ensure a safe and comfortable working environment.

We are the garbage sorting system manufacturer, in the environment industry, we mainly engage in research, manufacturing and sales of hydraulic products such as waste transfer equipment and waste sorting equipment.

Process Flow of Fully Automatic Baler

For fully automatic balers, it can be applied to many industries. And this is mostly because of its unique way that many companies like it very much, especially the bulk materials industry. For the bulk materials industry, what they are most afraid of is product quality and safety. General packaging equipment cannot effectively guarantee the quality of loose materials. For the straw baler, its unique hydraulic packaging technology can completely achieve aseptic packaging.

The tape is delivered to the position → the binding signal is received → the brake is released, the main motor is started → the right ejector is raised, and the right belt is placed on the slide → the “T” guide is retracted → the proximity switch senses the ejection probe → the main motor stops, Brake pull-in → Packer unwinding belt motor rotates, withdrawing belt for 0.35 seconds → The belt is tightened and tied to the object → The main motor is started twice, the brake is pulled in → The large swing lever is pulled twice, the belt is tightened → the left acrosome is raised.

Tighten the lower layer of tape → the heating sheet extends into the middle of the two tapes → the middle ejector rises, cuts the tape → the middle ejector drops → the middle ejector rises again to make the two straps firmly adhered → the middle ejector falls, and the left and right ejectors descend simultaneously → Heater plate reset → Slide back → “T” -shaped guide plate reset → Proximity switch senses the tape-feeding probe → The tape-feeding motor starts and drives the tape to send the tape → Reset of the large swing bar → The tape is in place and the head is pushed to the “T” -shaped plate The proximity switch senses the double probe → the main motor stops, the brake pulls in → the packer completes a working cycle.

Safe use of fully automatic balers:

Automatic baler & sorting project china still needs human manipulation, monitoring and maintenance. Its operation is in a human-machine environment. From the perspective of safety, we must ensure the safety of people, machines and the environment It is necessary to coordinate human-machine relations to ensure system security. Therefore, in the process of using the automatic baler, pay attention to some safety matters.

The first thing to note is that before operating the baler, the operator must read the instruction manual in detail.

Automatic Tie Baler Machine

In real life, many people will ignore the role of operating instructions. Even if they consult others, they are unwilling to read the instructions in detail, so they ignore many issues that need attention, and even cause property and personal loss. It should be known that, under the requirements of national regulations, manufacturers will include issues that need attention in the operating instructions. Secondly, when operating the machine, the operator must not place the body parts in a space accessible by the rear folding cover to prevent accidents. Also, for safety, be sure to turn off the power and air supply when installing and removing the tape and during normal maintenance or repair. The last thing to say is untrained personnel. Please do not approach or touch the machine at will, and do not cause unnecessary injuries because of curiosity.

The use of an automatic tie baler machine should not only pay attention to the above, but also pay attention to the design of the mechanical working space. The working space of the packer should ensure that the operator has sufficient room for movement in accordance with psychological and physiological requirements; there should also be enough space and safe passages at dangerous work sites to avoid in unexpected situations.
